Monessen · LoRider Vent-Free Firebox
Flames close to the floor, the way a real hearth sits
LoRider pairs a flush, low hearth with a tall opening, so the fire reads like a classic wood-burning fireplace. Choose 36 or 42 inches and one of four interior panel styles.
01 · Hearth
Flush, low hearth
The hearth sits nearly at floor level, which puts the flames right where your eye lands.
02 · Viewing
Tall, wide opening
A large viewing area shows off a full log set or a modern glass burner.
Fuel & Compatibility
This firebox does not burn fuel by itself. Use only an approved gas-fired decorative room heater and its matched log set. The separately selected burner determines fuel, ignition and heat input. Do not burn wood in this firebox.
Product Details
- Flush-hearth design with an expansive viewing area.
- Mesh screens retract into hideaway pockets.
- Clean-face appearance works with a planned tile, stone or mantel finish.
- See the SKU table for the selected interior configuration.
What comes with your order
Selected Lo-Rider firebox with its listed interior configuration, hood and mesh screens. Approved burner, logs and optional accessories are sold separately.
Manuals, Specifications & Warranty
Download the documents below. Match the exact SKU, fuel and product edition before planning or installation.
- Installation Manual — Rev M, 11/25PDF ↗
- Owner’s Manual — Rev F, 11/24PDF ↗
- Dimensions & Framing Guide — 12/25PDF ↗
- Limited Warranty — Rev N, 12/23PDF ↗
- Dimensions & Framing Guide — 12/25PDF ↗
Manufacturer warranty
The current Hearth & Home Technologies limited warranty provides 20 years of parts coverage and 3 years of labor for the gas firebox/heat exchanger. Other components have different coverage periods. Purchase, installation, maintenance and other conditions and exclusions apply.
Questions Before You Order
Are the burner and logs included?
No. This is a firebox listing. Choose a manufacturer-approved burner and compatible log set separately.
Can I use the nominal size as the framing dimension?
No. Use the model-specific framing dimensions and required clearances in the installation manual. The nominal size refers to the firebox family, not the complete installation opening.
Specifications & Installation Dimensions
36 in · Monessen LoRider 36 Vent-Free Firebox
| Brand | Monessen |
|---|---|
| Product type | Vent-Free Firebox |
| Material | Steel |
| Appliance front width | 42" |
| Appliance rear width | 29-1/2" |
| Appliance height | 34" |
| Appliance depth | 23" |
| Viewing area | 36 × 30 inches |
| Framing front width | 42-1/2" |
| Framing rear width | 42-1/2" |
| Framing height | 34-1/4" |
| Framing depth | 22-3/4" |
Model & Configuration
| SKU | Configuration |
|---|---|
| LCUF36CR-C | 36" Lo-Rider Clean Face Firebox with Cement Gray Stacked Traditional interior panels |
| LCUF36CR-BT | 36" Lo-Rider Clean Face Firebox with Multi-tonal Brown Stacked Traditional interior panels |
| LCUF36CR-GT | 36" Lo-Rider Clean Face Firebox with Multi-tonal Gray Stacked Traditional interior panels |
| LCUF36CR-GH | 36" Lo-Rider Clean Face Firebox with Multi-tonal Gray Herringbone interior panels |
Confirm all framing, clearance and finishing dimensions with your qualified installer before ordering or construction. Product dimensions and shipping-package dimensions are not interchangeable.
42 in · Monessen LoRider 42 Vent-Free Firebox
| Brand | Monessen |
|---|---|
| Product type | Vent-Free Firebox |
| Material | Steel |
| Appliance front width | 48" |
| Appliance rear width | 35-1/2" |
| Appliance height | 34" |
| Appliance depth | 23" |
| Viewing area | 42 × 30 inches |
| Framing front width | 48-1/2" |
| Framing rear width | 48-1/2" |
| Framing height | 34-1/4" |
| Framing depth | 22-3/4" |
Model & Configuration
| SKU | Configuration |
|---|---|
| LCUF42CR-C | 42" Lo-Rider Clean Face Firebox with Cement Gray Stacked Traditional interior panels |
| LCUF42CR-BT | 42" Lo-Rider Clean Face Firebox with Multi-tonal Brown Stacked Traditional interior panels |
| LCUF42CR-GT | 42" Lo-Rider Clean Face Firebox with Multi-tonal Gray Traditional Stacked interior panels |
| LCUF42CR-GH | 42" Lo-Rider Clean Face Firebox with Multi-tonal Gray Herringbone interior panels |
Confirm all framing, clearance and finishing dimensions with your qualified installer before ordering or construction. Product dimensions and shipping-package dimensions are not interchangeable.
Choose your configuration
Check your fuel, fit and required components, then select your model.
