Majestic · Direct Vent Gas Fireplace
Gas warmth at the touch of a button, built into your wall.
A sealed direct vent firebox draws combustion air from outside and sends exhaust back out, so the room air stays in the room while you enjoy a real flame without wood to haul or ash to clean. Configure the size, finishing front and interior in the builder above; only parts listed by the manufacturer for your exact model are shown.
Performance Highlights
Designed around your space
- Clear LED dimmable lights
- RC400 remote control
- Battery backup
- Ceramic glass
- Standard bronze glass media
Fuel Details
Ships as a natural gas unit. Propane conversion uses the approved kit (LPK-ECHEL36, LPK-ECHEL48), selectable in the builder above and installed by a qualified technician.
Venting components are specific to your installation and are not included. Call us with your vent route and we will help plan the parts list with your installer.
Maximum input varies by model and fuel. Compare the SKU-specific ratings in the specifications table below.
Product Details
What It Comes With
Selected Majestic Echelon II See-Through Direct Vent Gas Fireplace appliance, plus the listed factory-supplied components.
- IntelliFire Touch black remote control
- Glass, Bronze
Fronts, venting, finishing materials and installation are sold separately unless listed here.
Manufacturer warranty
The applicable Hearth & Home Technologies limited warranty sets coverage periods, component coverage, eligibility and exclusions. Review the written warranty supplied with the appliance and the linked owner’s manual; contact Smokeforges for the policy that applies to your model.
Project support
Got a project? Let’s plan the right parts.
Share your fireplace model, measurements and finish preferences. Ask about project or bulk pricing when ordering multiple units.
Specifications & Dimensions
| Specification | ECHEL36STIN-C | ECHEL48STIN-C |
|---|---|---|
| BTU input | 30,000 (NG); 27,000 (LP) | 40,000 (NG); 34,000 (LP) |
| Heating capacity | Up to 900 sq ft | Up to 1,300 sq ft |
| Viewing area | 35-1/2 × 12-1/2" | 47-1/2 × 12-1/2" |
| Efficiency | 55.0% (NG) / 60% (LP) | 48.7% (NG) / 62% (LP) |
| Venting | Direct Vent | Direct Vent |
| Overall width | 46-3/16" | 58" |
| Overall height | 41-3/4" | 41-3/4" |
| Overall depth | 17-1/8" | 17-1/8" |
| Framing width | 48-1/4" | 60-1/4" |
| Framing height | 42" | 42" |
| Framing depth | 17" | 17" |
| LP conversion kit | LPK-ECHEL36 | LPK-ECHEL48 |
| UPC | 652174930913 | 652174930937 |
| Shipping weight | 240 lb | 290 lb |
Dimensions are in inches unless stated otherwise. Nominal size and viewing area are not the rough opening. Confirm the exact model, revision, vent route, clearances and finishing method in the installation manual before framing. The model-specific installation manual controls where a general guide differs.
Manuals, Spec Sheets & Installation
Use the document for the exact selected model and revision. Shared manuals list the covered model numbers inside the document.
