Majestic · Direct Vent Gas Insert
Turn a drafty masonry fireplace into an efficient gas fire.
This direct vent insert slides into an existing fireplace opening and vents through liners run up the chimney, giving you dependable gas heat and a clean, finished look without rebuilding the fireplace. Configure the size, finishing front and interior in the builder above; only parts listed by the manufacturer for your exact model are shown.
Performance Highlights
Designed around your space
- IntelliFire Touch ignition system
- 30-inch and 35-inch sizes
- Direct vent through chimney liner kits
- Optional birch log set models
- Reflective black glass or traditional brick interior options
- Optional fan kit (35-inch model)
- Wi-Fi module and wall switch control options
Fuel Details
Available as natural gas or propane models.
Venting components are specific to your installation and are not included. Call us with your vent route and we will help plan the parts list with your installer.
Maximum input varies by model and fuel. Compare the SKU-specific ratings in the specifications table below.
Product Details
What It Comes With
- One Ruby Platinum Direct Vent Gas Fireplace Insert in the selected model and fuel configuration
- Factory log configuration for the selected model
- IntelliFire Touch ignition and LED ember bed
Required finishing selections sold separately: Front, door or surround, Insert venting kit. Venting or chimney components, optional accessories, construction materials and installation are sold separately unless explicitly included above.
Manufacturer warranty
The applicable Hearth & Home Technologies limited warranty sets coverage periods, component coverage, eligibility and exclusions. Review the written warranty supplied with the appliance and the linked owner’s manual; contact Smokeforges for the policy that applies to your model.
Project support
Got a project? Let’s plan the right parts.
Share your fireplace model, measurements and finish preferences. Ask about project or bulk pricing when ordering multiple units.
Specifications & Dimensions
| Specification | RUBYP30IL | RUBYP30IN | RUBYP30IN-BIR | RUBYP35IL | RUBYP35IN | RUBYP35IN-BIR |
|---|---|---|---|---|---|---|
| BTU input | 25,000 (LP) | 27,000 (NG) | 27,000 (NG); 25,000 (LP) | 28,000 (LP) | 32,700 (NG) | 32,700 (NG); 28,000 (LP) |
| Viewing area | 27-1/2" × 15-15/16" | 27-1/2" × 15-15/16" | 27-1/2" × 15-15/16" | 32-1/2" × 19-3/8" | 32-1/2" × 19-3/8" | 32-1/2" × 19-3/8" |
| Venting | Direct Vent | Direct Vent | Direct Vent | Direct Vent | Direct Vent | Direct Vent |
| Ignition | IntelliFire Touch | IntelliFire Touch | IntelliFire Touch | IntelliFire Touch | IntelliFire Touch | IntelliFire Touch |
| Overall height | 20-3/4" | 20-3/4" | 20-3/4" | 24" | 24" | 24" |
| Overall depth | 14-1/2" | 14-1/2" | 14-1/2" | 14-1/2" | 14-1/2" | 14-1/2" |
| Min. opening width | 31-5/8" | 31-5/8" | 31-5/8" | 36-5/8" | 36-5/8" | 36-5/8" |
| Min. opening height | 21" | 21" | 21" | 24-1/4" | 24-1/4" | 24-1/4" |
| Min. opening depth | 15" | 15" | 15" | 15" | 15" | 15" |
| LP conversion kit | See model manual | See model manual | LPK-MI-IFT | See model manual | See model manual | LPK-MI-IPI |
| UPC | 197250032056 | 197250032032 | 197250032049 | 197250034128 | 197250034104 | 197250034111 |
| Shipping weight | 97 lb | 97 lb | 97 lb | 117 lb | 117 lb | 117 lb |
Dimensions are in inches unless stated otherwise. Nominal size and viewing area are not the rough opening. Confirm the exact model, revision, vent route, clearances and finishing method in the installation manual before framing. The model-specific installation manual controls where a general guide differs.
Manuals, Spec Sheets & Installation
Use the document for the exact selected model and revision. Shared manuals list the covered model numbers inside the document.
